Cinebot 25 V2/ Modular System, Without Limits
https://youtu.be/6g32l-niU4o?si=viloB-hcOENPXryu
GEPRC's Cinebot25 V2 raises the bar for 2.5" cinewhoops with a shock-absorbing, quick-release modular camera system built specifically around the DJI O4 Air Unit Pro. The digital transmission module floats inside its own vibration-isolated housing, decoupling it from frame vibration for noticeably smoother, cleaner HD footage — while making swaps between frames fast and tool-friendly.
The result: buttery-smooth cinematic footage, a cleaner build process, and a modular platform designed to grow with future frame releases. Whether you're flying tight indoor lines or cruising for cinematic B-roll, the Cinebot25 V2 delivers the flexibility, durability, and image quality serious FPV pilots expect — at a price that doesn't require compromise.
Why You'll Love It
• DJI O4 Air Unit Pro Integration – The latest DJI digital FPV system, delivering crisp low-latency HD video straight out of the box.
• Vibration-Damped Quick-Release VTX Module – The O4 Air Unit sits in its own suspended housing, isolating it from frame vibration for smoother footage and fast, tool-light module changes.
• One Core, Multiple Frames – The damped module is designed to carry over across the 2.5" platform and future GEPRC frames, so your camera investment isn't locked to a single airframe.
• Optimized Frame & Electronics Bay – A refined GEP-CT25 V2 structure with a high-coverage electronics bay for better component protection and cleaner cable management.
• Dedicated Function Board – Integrated buzzer, LED strip BEC, and USB tuning port keep your build clean and your tuning workflow fast.
• Precision-Molded Canopy – Purpose-built to shield the DJI O4 Pro camera lens from impacts and debris.
Specifications
Model Cinebot25 V2 O4 Pro Quadcopter
Frame GEP-CT25 V2
Main Carbon Plate Thickness 2.0 mm
Wheelbase 123 mm
Flight Controller TAKER F722 35A 32Bit AIO
MCU STM32F722RET6
Gyro ICM42688-P
FC Firmware GEPRC_F722_AIO
Flash 16 MB
ESC 32-bit 35A
Motors SPEEDX2 1404 4600KV
Props HQProp DT63mm×3 V2
Battery Connector XT30
VTX DJI O4 Air Unit Pro
Camera DJI O4 Air Unit Pro camera module
Antenna DJI O4 Air Unit Pro antenna
Receiver PNP (built-in receiver) / ELRS 2.4G
Weight (ELRS 2.4G Version) 219±5g
GPS GEP-M10nano
Recommended Battery LiHV 4S 750–1100mAh
Flight Time 5–8 minutes (slow cruising conditions; actual time varies with flying style)
What's Included
• 1 × Cinebot25 V2 Quadcopter
• 2 × HQprop DT63mmx3 V2 (pairs)
• 1 × 15×150 mm Battery Strap
• 1 × L-shape Hex Wrench 1.5 mm
• 1 × Spare Screw Pack
• 1 × Battery Anti-Slip Pad
• 1 × Binding Pin
• 4 × Rear Landing Pads (Injection-molded)
• 2 × Front Bottom Landing Pads (Injection-molded)
• 1 × Front Top Cover
• 2 × O4 Antenna Mounts (Injection-molded)
• 2 × Acrylic Plates
• 3 × Damping Balls
Spare Screws Include:
• 2 × Press-fit Nuts
• 4 × M2×4 Button Head Hex Screws
• 3 × M2×10 Button Head Hex Screws
• 4 × M2×7 Button Head Hex Screws
• 3 × M2×6 Button Head Hex Screws
• 2 × M2×10 Socket Head Hex Screws
Note: Certain versions include 1 × Receiver Female Connector Cable (O4 Pro PNP).
