Dock 3 Compatible Drone System
DJI Matrice 4D & 4TD: Water and Dust-Resistant Enterprise Drones for Mapping, Inspection & Public Safety
The DJI Matrice 4D and Matrice 4TD are next-generation, water and dust-resistant enterprise drones engineered for seamless integration with DJI Dock 3, delivering extended flight time for automated, large-scale operations. For standalone missions, both models pair effortlessly with the DJI RC Plus 2 Enterprise remote controller.
Each drone comes equipped with a powerful four-sensor payload: a wide-angle camera, a medium tele camera, a tele camera, and a built-in Laser Range Finder - enabling precise data capture across diverse use cases.
DJI Matrice 4D: Precision Mapping & Surface Inspection
Purpose-built for professional high-precision mapping and detailed surface inspections, the Matrice 4D delivers the accuracy and reliability demanded by surveying, construction, and infrastructure monitoring professionals.
Features
- 20 MP wide-angle camera with 4/3 CMOS sensor and mechanical shutter.
- Dual 48 MP medium tele and tele cameras for detailed inspection tasks.
- Integrated laser range finder measures distances up to 1,800 m.
- Up to 47 minutes of flight time, extending to 54 minutes during forward flight.
- IP55-rated for dust and water resistance.
- Can operate standalone with RC Plus 2 or be integrated into DJI Dock 3 workflows.
- Omnidirectional obstacle sensing with wire-level detection down to 12 mm.
Specifications
Aircraft
| Spec | Detail |
|---|---|
| Takeoff Weight (with propellers) | 1219 g* *The standard weight of the aircraft (including the battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors. |
| Takeoff Weight (with Low-Noise propellers) | 1229 g* *The standard weight of the aircraft (including the battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors. |
| Max Takeoff Weight | Standard Propellers: 1420 g Low-Noise Propellers: 1430 g |
| Dimensions | Folded: 260.6×113.7×138.4 mm (L×W×H) Unfolded: 307.0×387.5×149.5 mm (L×W×H) Maximum dimensions excluding propellers. |
| Max Payload | 200 g |
| Propeller Size | 10.8 in |
| Diagonal Wheelbase | 438.8 mm |
| Max Ascent Speed | 10 m/s |
| Maximum Ascent Speed With Accessories | 6 m/s |
| Max Descent Speed | 8 m/s |
| Max Descent Speed With Accessories | 6 m/s |
| Max Horizontal Speed (at sea level, no wind) | 21 m/s 21 m/s flying forward, 18 m/s flying backward, 19 m/s flying sideways |
| Max Altitude | 6000 m |
| Max Operating Altitude with Payload | 4000 m |
| Max Flight Time (without wind) | 49 min (standard propellers) 46 min (low-noise propellers) Measured with the aircraft flying at approximately 9 m/s without payloads in a windless environment until the battery level reached 0%. Data is for reference only. Actual usage time may vary depending on the flight mode, accessories, and environment. Please pay attention to reminders in the app. |
| Max Hover Time (without wind) | 42 min (standard propellers) 39 min (low-noise propellers) Measured by the aircraft hovering in a windless environment at sea level, from 100% battery level until 0%. |
| Max Flight Distance (no wind) | 35 km (standard propellers) 32 km (low-noise propellers) Measured with the aircraft flying at approximately 14 m/s without payloads in a windless environment until the battery level reached 0%. Data is for reference only. Actual usage time may vary depending on the flight mode, accessories, and environment. Please pay attention to reminders in the app. |
| Max Wind Speed Resistance | 12 m/s* *Max wind speed resistance during takeoff and landing. |
| Max Pitch Angle | 35° |
| Operating Temperature | -10℃ to 40℃ (14°F to 104°F) |
| GNSS | GPS + Galileo + BeiDou + GLONASS* *GLONASS is supported only when the RTK module is enabled. |
| Hovering Accuracy Range (windless or breezy) | ±0.1 m (with Vision System); ±0.5 m (with GNSS); ±0.1 m (with RTK) |
| RTK GNSS Accuracy | RTK Fix: 1 cm + 1 ppm (horizontal), 1.5 cm + 1 ppm (vertical) |
| Internal Storage | N/A |
| Ports | E-Port interface × 1: Supports official accessories and third-party PSDK devices (hot-swapping is not supported) E-Port Lite interface × 1: supports USB connection to DJI tuning software and some third-party PSDK devices. Accessories or expansion modules must be installed before powering on. |
| Propeller Model | 1157F (standard propellers) 1154F (low noise propeller) |
| Beacon | Built into the aircraft |
Applications
From emergency response to energy infrastructure, the Matrice 4D adapts to the industries that need eyes in the sky most.
- Public Safety Agencies - Drones elevate public safety agencies by enhancing response times, reducing operational costs, and improving decision-making while ensuring the safety of personnel in critical operations.
- Powerline Inspection - Manage electrical grids and plants with drone solutions. Monitor construction, conduct inspections and maintenance with ease.
- Geographic Information - Perform topographic survey and generate a variety of data outputs with greater efficiency and reducing operational cost.
- Oil and Natural Gas - Revolutionizing the oil and gas industry by enhancing efficiency in management, inspection, and construction, while reducing costs and driving technological innovation.
- Renewable Energy - Flexible and mobile, capable of automatically inspecting along flight paths, effectively ensuring personnel safety and increasing power generation revenue.
- Roads and Bridges - Drones equipped with high-resolution cameras can meticulously inspect critical bridge components, including decks, piers, and cables.
- Water Conservancy & Maritime
What's Included
- DJI Matrice 4D Drone (RC Plus 2 Enterprise)
- RC Plus 2 Enterprise Controller
- 2 x Low-Noise Anti-Ice Spare Propeller
- 240W Power Adapter
- 240W Charging Hub
- Storage Case
- Carrying Case Strap
- Screwdriver Set
- Screwdriver for Remote Controller
- USB-C Data Cable
- USB-A to USB-C Data Cable
- Power Fast Charge Cable for Drones
- Gimbal Protector
- microSD Card
- 6 x M2.5 Propeller Blade Screw
- 6 x Rubber Propeller Washer
- 4 x M1.6 Aircraft Cellular Module Compartment Screw
